| Manufacturer |
LIEBHERR |
| Model |
RL64 Litronic Sideboom Pipelayer |
| Year of manufacture |
2009 |
| Recorded hours |
8.000 hours |
| Operating weight |
58.800 kgs |
| Lift capacity |
90.800 kgs |
| Certification |
CE |
| Engine make & model |
LIEBHERR D946L A6 |
| Engine output |
275 kW |
| Emission standards |
EU Stage IIIA & USA EPA Tier3 |
| Fuel tank capacity |
650 liters |
|
|
| Configuration |
ROPS cab with heating |
|
Air conditioning |
|
Long boom 10.500 mm with protection strips |
|
Track pads 914 mm |
|
Centre track guide |
|
Acoustic back-up alarm |
|
Four (04) removable counterweights |
|
Hydraulic driven winch |
|
Arctic kit (-40 degrees) |
|
Free fall control |
|
Load monitoring system |
|
Hydraulic PTO to drive a mandrel or a pipefacing machine |
| Transport dimensions (LxWxH) |
Base machine: 5.800 mm x 4.250 mm x 3.650 mm |
|
Weight base machine: 42.580 kgs |
|
Boom: 10.850 mm x 1.450 mm x 700 mm |
|
Weight boom: 3.850 kgs |
|
Counterweight - each: 1.750 mm x 1.500 mm x 500 mm |
|
Weight each: 3.230 kgs |
|
|
| Remarks |
Machine is currently rented |
|
|
|
|
|
|
| Product brochure |
Specifications Liebherr RL64 Litronic |
| Price |
Contact us for a detailed quotation including pictures and price |
